This antique red uni-line roof tile vent from Klober has been designed to be extremely discreet. Almost impossible to see from the roof line and compatible with most interlocking and plain roof tiles, this tile vent is suitable for a minimum pitch of 20° and allows direct ventilation to the roof space. It can also be used for mechanical extraction systems and as a terminal for soil and ventilation pipes, without additional adaptors required.

Why Choose the Manthorpe Uni-line Tile Vent?

In-line and discreet low-profile design
4mm louvred flyscreen grille
Profiles suits all top tile manufacturers
Suitable for use down to a 20˚ roof pitch
Fully independently wind tunnel tested
Base outlet feeds directly into roof space
Adaptor built in for mechanical extraction

Product Specifications:

Colour: Antique Red

Material: UPVC

Material Description: Soft and rigid UPVC

Minimum pitch: 20

Ventilation Area: 10000 mm2

Vent tile spacing 5 000 mm2: 2 m

Vent tile spacing 10 000 mm2: 1 m

Vent tile spacing 25 000 mm2: 0.4 m

Airflow resistance 15 litres/sec: 3.5 pascals

Airflow resistance 30 litres/sec: 14 pascals

Airflow resistance 60 litres/sec: 56 pascals
